Butyl Tubes Size Available
| DIAMETER
(MM) |
ETRTO
(MM) |
ALTERNATIVE
SIZE |
WEIGHT
AVERAGE |
|---|---|---|---|
| 152 | 10 x 1.75 x 2 | 58 | |
| 203 | 37/54-203 54/62-203 |
12 ½ x 1.50-2.10 12 ½ x 2.10-2.50 |
57 84 |
| 254-288 | 37/54-254/288 | 14 x 1.50-2.10 | 90 |
| 305 | 37/54-305 54/62-305 |
16 x 1.50-2.10 16 x 2.10-2.50 |
97 113 |
| 355 | 37/54-55 | 18 x 1.50-2.10 | 112 |
| 406 | 25/37-406 37/54-406 54/62-406 |
20 x 1.00-1.50 20 x 1.50-2.10 20 x 2.10-2.50 |
84 124 142 |
| 451 | 25/37-51 | 20 x 1.3/8 | 91 |
| 507 | 37/54-507 54/62-507 |
24 x 1.5-2.10 24 x 2.10-2.50 |
153 173 |
| 540 | 25/37-540 | 24 x 1 x 1.3/8 | 106 |
| 559 | 25/37-559 37/54-559 54/62-559 |
26 x 1.00-1.50 26 x 1.50-2.10 26 x 2.10-2.50 |
110 164 189 |
| 584 597 |
25/37-584/597 37/54-584/597 37/54-584/597 54/62-584/597 |
26 x 1 x 1.3/8 27.5 x 1.5-2.10 26 x 2 x 1 ½ 27.5 x 2.10-2.50 |
115 170 170 195 |
| 622 635 |
18/25-622/635 25/37-622/635 35/54-622/635 54/62-622/635 |
700 x 18/25c 700 x 25/35c 28/29 x 1.5-2.10 28/29 x 2.10-2.50 |
79 119 182 209 |
| PLUS SIZE | |||
| 584 | 62/75-584 | 27.5 x 2.50-300 | 245 |
| 622 | 62/75-622 | 29 x 2.5-300 | 260 |
